Architecture
barebill is a local-first WPF desktop application built on .NET 10, using MVVM and SQLite.
Tech stack
| Concern | Technology |
|---|---|
| UI | WPF (.NET 10), MVVM |
| Database | SQLite via Microsoft.Data.Sqlite |
| DI | Microsoft.Extensions.DependencyInjection |
| Logging | Microsoft.Extensions.Logging |
| Markdown | Markdig |
| Testing | xUnit, Moq, FluentAssertions |
Solution structure
src/
WorkTracking.sln
WorkTracking.Core/ # Domain models + business logic (no dependencies)
WorkTracking.Data/ # SQLite repositories + schema initialisation
WorkTracking.UI/ # WPF app, MVVM, DI bootstrap
tests/
WorkTracking.Tests/ # xUnit integration + unit tests
docs/ # Internal dev docs
website/ # MkDocs source for this site
design/ # Affinity Designer source files for branding assets
MVVM pattern
ViewModels inherit from ViewModelBase (implements INotifyPropertyChanged). Views bind via DataContext set through DI — no new ViewModel() in code-behind.
Commands are ICommand properties on ViewModels, implemented via RelayCommand.
Data layer
All database access goes through repository interfaces. No raw SQL exists outside repository classes.
Schema is applied at startup via SchemaInitializer (idempotent). Migrations live in WorkTracking.Data/Migrations/ as numbered SQL files.
Data is stored at %APPDATA%\barebill\barebill.db.
Dependency injection
Registrations are in WorkTracking.UI/DependencyInjection/ServiceCollectionExtensions.cs:
- Repositories — Scoped
- ViewModels — Transient
- Services (
IDialogService,INavigationService) — Singleton
Running locally
Prerequisites
- Windows 10/11
- .NET 10 SDK
- Visual Studio 2022 17.10+ or VS 2026
Build and run
git clone https://github.com/codebureau/barebill
cd barebill
dotnet build src/WorkTracking.slnx
dotnet run --project src/WorkTracking.UI
